TPX6111 Series Horizontal Boring & Milling Machine
Heavy-duty horizontal boring and milling machine series (TPX6111 / TPX6113 class) for large box-type parts, with Φ110–Φ130 mm spindle and worktable up to 2000 × 1600 mm.
- CategoryHorizontal Boring Machine
- Φ110 mm spindle, table 1100 × 900 mmHBM-TPX6111B-110
- Φ130 mm spindle, table 1600 × 1400 mmHBM-TPX6113-130
- Φ130 mm spindle, table 2000 × 1600 mmHBM-TPX6113-2000
Price and lead time are quoted per configuration and quantity. Send us your part or capacity requirement and we will come back with a quotation.
The TPX6111 series is a heavy-duty horizontal boring and milling machine intended for boring, drilling, milling, facing and thread cutting on medium to large workpieces. The horizontal spindle layout keeps large box-type parts within reach of the tool, so several faces can be machined with fewer re-clampings.
Typical configurations span several spindle diameters and table sizes, letting the machine be matched to the size and weight of the parts machined most often.
Typical Specifications
| Item | Typical reference range |
|---|---|
| Boring spindle diameter | Φ110 – Φ130 mm |
| Worktable size | 1100 × 900 – 2000 × 1600 mm |
| X / Y / Z travel | 1200 × 900 × 1200 – 2000 × 1400 × 1600 mm |
| Boring spindle speed | 8 – 1000 rpm, stepless (typical) |
| Spindle motor power | 7.5 – 11 kW |
| Facing head diameter | Φ600 – Φ800 mm |
| Positioning accuracy | approx. ±0.02 mm / full stroke (reference) |
| Table load capacity | 2500 – 6000 kg |
| Tool magazine | 24 – 40 tools (optional, configuration-dependent) |
The values above are typical industry reference ranges offered for selection purposes only; final configuration and quotation are subject to confirmed inquiry.
Suitable Workpieces
The horizontal layout suits large box-type castings and weldments: gearbox and reducer housings, pump and valve bodies, machine frames, generator end shields and similar parts where multiple bores must stay coaxial. It is also used for facing large flanges and milling flat mating surfaces on heavy parts.
Structural Rigidity Highlights
The bed and column are proportioned for heavy cutting, with a box-section column and ribbed bed to limit deflection under load. The spindle assembly runs in precision bearings to keep boring accuracy stable over long cuts, while the counterweight and guideway design help maintain smooth travel of the headstock.
Selection & Foundation Installation Notes
When selecting, match spindle diameter and table size to the largest and heaviest part you intend to machine, and confirm the required travels against the part envelope. The machine should be set on a rigid, level foundation with adequate vibration isolation, and alignment should be re-checked after installation.
Need a Different Configuration?
Tell us the parts you machine and the batch size — we will recommend a machine or process that fits.
